Sound Diffuser Build Gallery

To help get your creative juices flowing, here are some examples of the sound diffusers people have built using these blueprints. This is just a small selection of the DIY diffuser build photos people have sent me. If you have photos of a build you're happy with and you'd like me to post them, please email them to .

If you've not yet grabbed the blueprints, you can download them for free here. For more information about these optimized stepped diffuser designs (and acoustic diffusers in general) visit the sound diffusers 101 page or download the diffuser design thesis.

Castle Mastering Studio uses 7 Leanfuser™ panels on rear wall

Audiobomber's Castle Mastering Studio uses arrays of Leanfuser panels on the rear and side wall. This studio is built inside Castle Wildberg, a medieval castle in Upper Austria! Built by owner and mastering engineer Alexander Jöchtl (better known as Audiobomber). Castle Mastering features other acoustic treatments built by Alex, including DIY bass traps and ceiling clouds.

Leanfuser panels on the walls of Audiobomber's Castle Mastering (Alexander Jöchtl's mastering studio at Castle Wildberg in Upper Austria). Photos by Karin Lohberger Photography.

Wood Leanfuser panels built into the the rear wall of Castle Mastering, Alexander Jöchtl's mastering studio at Castle Wildberg. Photo credit: Karin Lohberger Photography.

Castle Mastering studio at Castle Wildberg in Upper Austria, featuring DIY acoustic treatments (bass traps, diffusers and ceiling cloud). Built and run by mastering engineer Alexander Jöchtl (Audiobomber). Photos by Karin Lohberger Photography.

Test assembly of 7 Leanfuser panels using the Profiled Modulation 2 (panels are mounted at specific depths to reduce periodicity, which dramatically improves diffusion performance). Prior to mounting in the rear wall of Castle Mastering Studio.

Diffusers built by John White: Leanfuser™ array with modulation

DIY sound diffuser array (Leanfuser modules with Profiled Modulation 1) build by John White at (White Construction Design).

DIY sound diffuser array and acoustic treatments in a music room built by John White (whiteconstructiondesign.com).

Acoustic treatments and DIY sound diffusers in studio room built by John White at (White Construction Design).

DIY sound diffuser array and acoustic treatments in a music room built by John White (whiteconstructiondesign.com).

Fractal diffusers built by Hai Trieu: Stepfractal™ & Leanfractal™

Fractal sound diffusers mounted on the walls of a listening room. Built by Hai Trieu. The ceiling and back wall (not shown) feature 2D bamboo QRD diffusers.

Stepfractal diffusers (front wall) and Leanfractal diffusers (side walls) mounted in a listening room. Built by Hai Trieu. The ceiling and back wall (not shown) feature 2D bamboo QRD diffusers.

Leanfractal™ sound diffuser build process by Pablo Crespo

Fractal sound diffusers DIY build: 5 Leanfractal (A1-Frac) diffuser modules assembled using Profiled Modulation 1. Built by Pablo Crespo. Note that couch is not used for critical listening (the diffusers are not designed for such close proximity).

Fractal acoustic diffusers DIY construction: 5 Leanfractal (A1-Frac) diffuser modules assembled using Profiled Modulation 1. Built by Pablo Crespo. Note that couch is not used for critical listening (the diffusers are not designed for such close proximity).

DIY building the Leanfractal (A1-Frac) fractal sound diffuser. Step 1: First Glue Applied. Built by Pablo Crespo.

DIY building the Leanfractal (A1-Frac) fractal sound diffuser. Step 2: Second Glue Applied. Built by Pablo Crespo.

DIY building the Leanfractal (A1-Frac) fractal sound diffuser. Detailed view of mounting the fractal cells. Built by Pablo Crespo.

DIY construction of the Leanfractal (A1-Frac) sound diffuser. Fractal cells mounted on MDF boards. Built by Pablo Crespo.

Fractal Acoustic Diffuser DIY Construction: Presentation of the parts to make one Leanfractal module (dry assembly, prior to gluing). Expanding on the simpler Leanfuser stepped diffuser, the Leanfractal adds fractal cells to increase the diffusion bandwidth. Built by Pablo Crespo.

Fractal Acoustic Diffuser DIY Construction: Painting a Leanfractal (A1-Frac) module. Built by Pablo Crespo.

DIY construction of the Leanfractal sound diffuser. 25 fractal cells are ready for mounting onto 5 Leanfuser (A1-LF) modules. The result will be 5 Leanfractal (A1-Frac) diffuser modules. Built by Pablo Crespo.

Stepfractal™ fractal diffuser array built by Kalakula Studio

Stepfractal diffusers built by Steven Mazzotta at Kalakula Studio, Atlanta, GA. The fractal cells are made out of basswood, carved with a dado saw and mounted on vertical panel cuts. Build process is shown below.

Three Leanfuser™ panels flanked by DIY QRD diffusers

Three Leanfuser sound diffuser panels flanked by QRD diffusers. Center panel protrudes 8 cm out from side panels. Built by Michael (tinnitusintx on Gearslutz).

Three Leanfuser stepped diffuser panels flanked by QRD diffusers. Center panel protrudes 8 cm out from side panels. Built by Michael (tinnitusintx on Gearslutz).

Three Leanfuser acoustic diffuser panels flanked by QRD diffusers. Center panel protrudes 8 cm out from side panels. Built by Michael (tinnitusintx on Gearslutz).

Plywood Leanfuser™ panel array (modulated) built by Chris Rude

"This diffuser build was very inexpensive and despite the cheap materials, I think it looks great!

More importantly, I immediately noticed the difference in my space, where the flutter echo in my basement studio was instantly transformed into a much more pleasing reverberation.

The finish is just 2 coats of lightly tinted poly over plywood. Very inexpensive, but when you cut across the grain of the plywood, you get a cool tiger stripe effect.

My zero depth wells are made from painted MDF to make each module look smaller and help break up the overall girth of the object.

I am very happy with the finished product!"

–Chris Rude (RudeGuitar.com)

Modified Leanfractal™ (with wells) built at Sanford Brown College

Jeff Sansone, the audio production lead at IADT School of Technology (Sanford Brown College), build this fractal sound diffuser out of poplar.

The design is based on the 7-module Leanfractal, but fins (separators) have been used between the wells. Note that the Leanfractal was designed to function without fins, so the effect these fins have on diffusion performance is unknown. The fins give the diffuser an aesthetic similar to a fractal QRD diffuser (like the RPG Diffractal).

More acoustic diffuser build photos to come!

by Tim Perry
